DS Series 4x6" Coax
Price:
The 2014 DS Coaxials are a drop-in coaxial upgrade with the flexibility to fit nearly any vehicles doors for a vast improvement over factory sound.

DS-Series 4x6" Coaxial

The 2014 DS 4x6-Inch Speakers give you an instant upgrade from factory sound.

Using zero protrusion PEI tweeters ensures you get every bit of clarity you need, without interfering with factory grilles. A polypropylene cone with EVC™ (Extended Voice Coil) technology gives you deep bass and outstanding sonic quality. Add a DX amplifier to increase the level and quality of the volume in your ride.

These DS speakers work best with 30 watts of recommended power. See below for more details.

DSC464 Specifications
Speaker Design
2 - way
Woofer [in, mm]
4x6, 100x160
Tweeter [in, mm]
1/2, 13
Rated Impedance [Ω]
4
Peak Power Handling [Watts]
120
Continuous Power Handling [Watts RMS]
30
Sensitivity [1W, 1m]
88
Frequency Response [Hz]
50-20k
Mounting Hole Diameter [in, mm]
4x6, 101x152
Top Mount Depth [in, mm]
5/16, 7
Bottom Mount Depth [in, mm]
1-11/16, 43
Tweeter Protrusion [in, mm]
0
Grilles
No
Tweeter Magnet Material
Neodymium
Tweeter Dome Materia
PEI (polyether imide)
Tweeter Design
Balanced dome
Woofer Cone Material
Polypropylene
Woofer Surround Material
Polyester foam

*Power handling assumes typical music program with minimal clipping. See your KICKER dealer for complete details. Based on measurements of 4Ω models.
