15" CompC 4 Ohm SVC
Huge value. High performance. The KICKER® CompC™ Subwoofer pumps out the bass with all the intensity your ears can handle.

15" CompC 4 Ohm SVC

A thick stamped steel basket holds an injection-molded polypropylene cone with stabilizing ribs in the surround. Next-level engineering like this delivers clean, undistorted bass every time you turn it up!

Features:

  • Four-Ohm Voice Coil
  • Injection-Molded Polypropylene Cone
  • Perimeter Venting for Thermal Management
  • Ribbed Polyurethane Surround
  • Signature Yellow Surround Stitching
  • High-Strength Spiralead™ Tinsel Leads
  • Stamped Steel Basket
  • High Temp Voice Coil
  • Spring-Loaded Speaker Terminals

Want setup help? Go to KICKERU for a free woofer & amplifier configuration app!

*The CompC 12-Inch Subwoofer works best with a sealed or ported enclosure and 300 watts of recommended power. See below for more details.

Specifications
Thiele/Small Parameters
TS Parameters PDF link 44CWCS154 T/S Parameters PDF
Size (IN.,CM)
15, 38
Impedance (OHMS)
4 SVC
Recommended Amplifier Power (watts RMS)
600
Peak Power (watts, per ANSI/CTA-2031-A)
1200
Sensitivity (dB 1w/1m)
90.3
Frequency Response (Hz)
25-500
Mounting Depth (in, cm)
7, 17.7
Mounting Cutout (in, cm)
13-3/4, 35
Min Sealed Box Vol (cu. ft, L)
2.25, 63.7
Max Sealed Box Vol (cu. ft, L)
5.0, 141.6
Min Vented Box Vol (cu. ft, L)
3.0, 85
Max Vented Box Vol (cu. ft, L)
4.0, 113.3

*Assumes typical music program with minimal amplifier clipping; varies with enclosure size. See your KICKER dealer for details.

**Port Volume Excluded.

Due to continual developement, product, and specifications are subject to change without notice. Stillwater Designs and it's agents are not responsible for typographical errors.
