KXMA1200.1 Amplifier
KXM Amplifiers are built for fun, no matter where you go. Power, speaker and input connections are gasket-sealed, as is the control cover hiding the settings, creating a water-resistant barrier to key components.

KXMA1200.1 Amplifier

The KXM 1200-watt mono amplifier uses Class D technology for huge power in a small chassis. KickEQ+™ provides an enormous 18dB of variable bass boost, while a powerful 24dB crossover and subsonic filter to give you the acoustic control to quickly perfect your sound.

A wireless controller is also included for perfecting your sound on the fly. Monitor and adjust gain, bass boost, clipping and more without leaving the driver's seat!

Features:

  • Class D Power Plant
  • One-Ohm Stable
  • SHOCwave™ Bass Restoration Processor
  • KXARC Wireless Remote Included
  • Gain Control With "Optimal Input" Indicator
  • Variable 24dB Subsonic Filter
  • FIT2™ (Fail-Safe Integration Technology) Circuitry
  • Variable 24dB Crossover
  • DSP-Controlled Preamp
  • KickEQ+™ 18dB Variable Bass Boost
  • ABYC/NMMA Compliant Power Terminals
  • Conformal-Coated Circuit Boards
  • Easy Access to Settings behind Gasket-Sealed Cover Panel
  • Black Anodized Aluminum Chassis
  • Top-Mounted Teal LED Light Pipe
  • Stainless Steel Mounting Hardware Included

Want setup help? Go to KICKER U for a free woofer & amplifier configuration app!

This KXM amplifier delivers as much as 1200 watts into one channel. See below for more details.

Specifications
RMS Power [Watts]
@ 14.4V, 4Ω mono, ≤ 1% THD+N : 600 x 1
@ 14.4V, 2Ω mono, ≤ 1% THD+N : 1200 x 1
@ 14.4V, 1Ω mono, ≤ 1% THD+N : +/- 10%
Length [in, cm]
9-916 , 24.4
Height [in, cm]
2-⅛, 5.5
Width [in, cm]
8-516 , 21
Frequency Response ± 1dB
10Hz–160Hz
Signal-to-Noise Ratio
95dB
Input Sensitivity
250mV–10V
Selectable Electronic Crossover
Variable Lo-pass 40Hz–160Hz, 24dB/octave
Subsonic Filter
Variable 10–80Hz, 24dB/octave
KickEQ+™ Parametric Bass Boost
(Remote Control Adjustable)
Boost - Variable 0-18db
Center Frequency - 20Hz-80Hz
Bandwidth 1-5
Remote Bass
Yes
CEA Power
600 x 1 @ 4 ohms, 14.4VDC, 1% THD, CEA-2006B (Watts)
CEA Signal-to-Noise Ratio
-75dB CEA-2006B (ref: 1W, A-weighted)
